DATA LOGGING (LOG) GROUP
Display Adv Cal System Site Meter I/O Log
Select Data Setup Select Data Setup
Figure 79: Log Group
Setup
The setup screen controls the selection of the Logging Rate and has a software button for starting and stopping logging
sessions.
Site Name 0.00 GPM
03/28/2012
13:24
Log Display Adv Cal System Site Meter I/O
Select Data Setup
Data Log Status Stopped
Logging Rate 10 Sec
65500 Lines Max Per File
Last Log File Name: W Creek WWTP.csv
Number of Lines: 135 Duration: 11.25 Hours
Figure 80: Datalogging Setup
IMNOOTNO
I
To enable datalogging a site from the Site>Create must be either created or selected from previous site names. If a site is not chosen
the datalogger start/stop control button will not function and the control will be grayed out.
The logging rate entry tells the DXN how often to collect data points. The logger memory area has the capacity to store more
than 300 individual files consisting of a maximum of 65,500 points per log file.
The amount of time the logger will collect data depends on the Logging Rate the DXN is programmed for. In general the
logging time is calculated by dividing 65,563 by the number of data points recorded per minute.
Logging Time (Minutes) =
65,563
Number of Samples per Minute
