Multilingual Support
The user interface is capable of displaying in multiple languages with the press of a button:
• English • German • Italian
• Japanese • French • Spanish
• Russian • Swedish • Norwegian
• Dutch • Portuguese
NOTE: N The language selection icons can be found in the System>Misc or from the Status Bar Control (See Figure 40 )
SOFTWARE CONVENTIONS
The DXN uses a sophisticated touch screen user interface to control all functions. The tabbed menu tree provides access to
all controls and settings within two layers of menus. Large easy to read touchscreen buttons allow for gloved operation in
inclement weather.
Conventions and Controls
When describing navigating the DXN menus, this manual specifies first the group tab name, and then the Page, as
shown below.
Group Tab
Pages
Display
Alerts Graph Meters Graph Setup Table
Figure 9: Group/Page Convention
A typical reference would look like this: Display>Meters
Upon startup of the instrument using the back panel power button, the system will display a series of splash, progress, and
information screens.
For troubleshooting and advanced startup options for Windows, Press F8.
Resuming Windows
OEM Bios Version: Unknown
Board Serial Number: 637864
Attempting to boot hard drive 0...
Start
10/12/2011
13:24
Shortcut to
Quickstart.exe
Figure 10: Startup Screen Examples
