Transducer Mount Mode Transducer Pipe Material Pipe Size
W-Mount
DTTN/DTTH
Plastic (all types)
2…4" (50…100 mm)
Carbon Steel
Stainless Steel
Copper
Ductile Iron
Not recommended
Cast Iron
DTTL
Plastic (all types)
8…16" (203…406 mm)
Carbon Steel
Stainless Steel
Copper
Ductile Iron
Not recommended
Cast Iron
V-Mount
DTTN/DTTH
Plastic (all types)
4…12" (203…406 mm) Carbon Steel
Stainless Steel
Copper
4…30" (100…750 mm)
Ductile Iron
2…12" (50…300 mm)
Cast Iron
DTTL
Plastic (all types) 16…48" (406…1220 mm)
Carbon Steel
16…36" (406…915 mm)
Stainless Steel
Copper
16…48" (406…1220 mm)
Ductile Iron
16…30" (406…750 mm)
Cast Iron
Z-Mount
DTTN/DTTH
Plastic (all types) > 30" (> 750 mm)
Carbon Steel
> 12" (> 300 mm)
Stainless Steel
Copper
> 30" (> 750 mm)
Ductile Iron
> 12" (> 300 mm)
Cast Iron
DTTL
Plastic (all types) > 48" (> 1220 mm)
Carbon Steel
> 36 in. (> 915 mm)
Stainless Steel
Copper
> 48" (> 1220 mm)
Ductile Iron
> 30" (> 750 mm)
Cast Iron
Table 2: Starting Point Transducer Mounting Modes—DTTN, DTTL, and DTTH
