METER GROUP
Display Adv Cal System Site Log I/O Meter
Filter Energy Limit Totalizer Flow Filter Energy Limit Totalizer Flow
Figure 70: Meter group
Select the Meter Group from the Group bar at the top of the screen. When the Meter pages appear select the flow page to
enter information about the flow units to be used.
Flow Page
Site Name 0.00 GPM
1/16/2013
2:18 PM
Meter Display Adv Cal System Site Log I/O
Flow Filter Energy Limit Totalizer
Flow Units - Rate
Flow Units - Volume Gallons
Minutes
Hybrid Mode Fixed Transit Time
Figure 71: Flow Units Setup
Flow Units Volume [Engineering Units for Flow Rate]
Gallons Oil Barrels (42 Gallons) British Thermal Units
Liters Liquid Barrels (31.5 Gallons) Thousands of BTUs
Millions of Gallons Feet Millions of BTUs
Cubic Feet Meters Tons
Cubic Meters Pounds Kilojoule
Acre Foot Kilograms Kilowatt
Table 13: Flow Units
Select a desired engineering unit for flow rate measurements.
Flow Units Rate – Time Interval for Flow Rate
The flow interval can be any of the following:
• Seconds
• Minutes
• Hours
• Days
Select a desired time unit for flow rate measurements.
