Using the Help system
For information about program features, you can access the help program in any of the
following ways:
z z From the Extron Electronics program folder or group, double-click the
MATRIX Switcher Help icon (shown at right).
z z From within the Matrix Switchers Control Program, click Help > Contents
on the menu bar.
z z From within the Matrix Switchers Control Program, press the keyboard < F1 > key.
Button-Label Generator Program
The Button Label Generator software creates labels that you can place in the translucent
covers above and below the input and output pushbuttons. You can create labels with
names, alphanumeric characters, or even color bitmaps for easy and intuitive input and
output selection. See the “
Installation ” section for the procedure for removing and
replacing the translucent covers.
The Extron Button Label Generator is available on the Extron website,
www.extron.com ,
under the Download tab. Click the Software link (see figure 52), and download and install
the program on your PC.
Figure 52. Location of Software on the Website
NOTE: The Button Label Generator software is also included on the Extron Software
Products Disk that accompanied the switcher.
By default, the Windows installation creates a C:\Program Files \ Extron \
ButtonLabelGenerator directory and places the Button Label Generator icon into a group
or folder named “ Extron Electronics .”
MPX 866 A Media Presentation Matrix Switcher • HTML Operation 94
