Command/Response Table for SIS Commands (continued)
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Preset names
Write global preset name
EX1)
,
X1@
NG
}
Nmg
X1)
,
X1@]
Example:
E
1,Security 1NG
}
Nmg01
,
Security 1
]
Name global preset 1 “Security 1”.
Read global preset name
EX1)
NG
}
X1@]
Example:
E
2NG
}
Security 2
]
View ties, gain, volume, mutes, and presets
NOTES: • The ! read tie command for RGB and the % read tie command for video can be used interchangeably.
• When the switcher is in verbose mode 1 or 3, the response is Out
X@
•In
X!
•(RGB), (Vid), or (Aud)
]
.
View output video (RGB) tie
X@
&
X!]
Example:
5&
07
]
Input 7 computer video is tied to output 5.
View output video tie
X@
%
X!]
Example:
7%
12
]
Input 12 low resolution video is tied to output 7.
View output audio tie
X@
$
X!]
Example:
3$
06
]
Input 6 audio is tied to output 3.
View output volume
X@
V
X^]
Example:
7V
55
]
Volume for output 7 is 55%.
View input gain
X!
G
X&]
Example:
4G
–02
]
Gain for input 4 is -2 dB.
View output mutes
E
VM
}
X1!
1
X1!
2
...
X1!
12
]
Each
X1!
response is the mute status of an
output, starting from output 1.
Example:
E
VM
}
Mut023010000000
]
Output 2 audio is mute, output 3 video and
audio are muted, and output 5 video is muted.
All other outputs are unmuted.
NOTE: The “Mut” portion of the response appears only when the switcher is in Verbose mode 1 or 3. See the
Verbose mode
command
on
View input configuration
X#
\
X$]
Show the configuration of input
X#
.
NOTE
: The only valid input (
X#
) numbers are 11 through 14.
View global video preset
configuration
EX1)
*
X@
*1VC
}
X!
1
•
X!
2
• ... •
X!
16
•Vid
]
Show the configuration of preset
X1)
. Show
the input tied to 12 sequential outputs, starting
from output
X!
. (Video outputs 13 through 16
do not exist on this switcher model.)
Command description:
preset # (
X&
)*starting output # (
X@
) (should always be “1” for this switcher)*1 (= video)VC
Response description:
input # (
X!
) tied to output 1•
X!
tied to output 2•
X!
tied to output 3• ... •
X!
tied to output 16•Vid
]
Example:
E
4*1*1VC
}
01
Output:
Response = tied input:
Input 4 tied to output 3
02 03 04 05 06 07
13
No tied input
Computer/Audio Group
Video Group
Non-existent outputs
14 15 16
08 09 10 11 12
08•08•04•08•08•00•09•00•10•10•10•10•--•--•--•--•Vid
Each position shown in the response is an output: left = output 1 (the starting output number), right = output 16.
The number in each position is the input tied to that output. Outputs 13 through 16 do not exist on this matrix
switcher; the content of those positions is “--“.
In this example, video input 8 is tied to outputs 1, 2, 4, and 5; video input 4 is tied to output 3, video input 9 is
tied to output 7; video input 10 is tied to outputs 9, 10, 11, and 12. No inputs are tied to outputs 6 and 8.
NOTE:
EX1)
*1*1VC
}
where
X1)
= 0 returns the current video configuration of the switcher.
NOTE:
X!
= Input number (for tie)
00 (untied)
01 – 08 for the computer group
09 – 14 for the low resolution group
X@
= Output number
01 – 12 for video
01 – 06 for audio
X#
= Input number
11 – 14 (the only valid inputs for the / command)
X%
= Mute status
0 = off
1 = on
X1)
= Global preset #
32 maximum
X1!
= Video and audio mute:
0 = no mutes
1 = video mute
2 = audio mute
3 = video and audio mute
X1@
= Name
12 characters maximum
