Command/Response Table for SIS Commands (continued)
Command ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Lock (executive) modes
NOTE: See “ Setting the Front Panel Locks (Executive Modes) ” in the Operation section for more information on the Lock modes.
Lock all front panel functions 1X Exe1 ] Enable Lock mode 1.
Lock advanced front panel
functions 2X Exe2 ] Enable Lock mode 2.
Unlock all front panel
functions 0X Exe0 ] Enable Lock mode 0.
View lock status X X1*]
Resets
Reset global presets and
names E ZG } Zpg ] Clear all global presets and their names.
Reset one global preset EX1) ZG } Zpg X1)] Clear global preset X1) .
Reset audio input levels E ZA } Zpa ] Reset all audio input levels
(gain and attenuation) to 0 dB.
Reset audio output levels E ZV } Zpv ] Reset all audio output levels (volume) to 100%
(no attenuation).
Reset all mutes E ZZ } Zpz ] Unmute all outputs.
Reset whole switcher E ZXXX } Zpx ] Clear all ties and presets, reset all all audio
gains to 0 dB, and reset volume to 100%.
Absolute reset E ZQQQ } Zpq ] Similar to Reset whole switcher, plus
clear all UART ports, reset the IP address to
192.168.254.254 and reset the subnet mask to
255.255.000.000.
Information requests
Information request I V14X12•A14X06 ] This matrix switcher has 14 video and audio
inputs by 12 video and 6 audio outputs.
Request part number N 60-825-01 ]
NOTE: There are up to three separate sets of Extron firmware on which the switcher can report: the controller firmware, which is the
overall control firmware; the Ethernet protocol firmware, which handles the Ethernet interface; and the latest optional Extron
firmware update, which is available at
www.extron.com .
Query firmware version Q X1$]
Query controller firmware
version (verbose) 0Q X1$ - X1% - X1%] Provide a detailed status of the Ethernet protocol
firmware, the controller firmware, and any
firmware upgrade. An asterisk (*) marks the
firmware that is running is by . A caret (^)
marks that the firmware has a bad checksum
or an invalid load. ?.?? marks that firmware is
not loaded.
Response description: Ethernet protocol firmware version-controller firmware version-updated firmware version ]
Example: 0q
Ethernet
protocol
firmware
Description
MPX firmware version Updated firmware version
* indicates the version running Upload date and time
1.23-0.14(0.20-MPX866Series -Thu, 20 Jul 2006 00:00:00 GMT)-0.25*(0.24-64x64 Series -Fri, 28 Jul 2006 16:39:21 GMT)
Request system status S X1^ • X1^ • X1^ • X1^ • X1^ • X1^ • X1&]
Response description: S +3.3V•+5V•–5V•+2.5V•–15V•+15V•Temp ]
Example: S +15V power system at +15.15V
Temperature 120.20 degrees 3.3V power system at 3.29V
3.29•5.04•-5.14•2.48•-15.27•15.15•120.20
NOTE: X1) = Global preset # 32 maximum
X1$ = Firmware version number to second decimal place (x.xx)
X1% = Verbose firmware version-description-upload date/time. See above.
X1^ = Voltage Positive or negative voltage and magnitude
X1& = Temperature Degrees Fahrenheit
X1* = Front panel locks (Executive modes) 0 = Mode 0 1 = Mode 1 2 = Mode 2
MPX 866 A Media Presentation Matrix Switcher • Programming Guide 71
