g
View ( < ) button and LED — The View ( < ) button and LED have one primary function
(❏) and four secondary (•) functions:
❏
Selects View-Only mode, which displays the current configuration, and indicates its
selection.
NOTE: View-only mode also provides a way to mute and unmute the outputs
(see “ Muting and Unmuting Video and Audio Outputs ” on
page 34.
• Decrease the audio level of the selected input in Audio mode.
• Decrease the volume of the selected output in Audio mode.
• With the Enter, Preset, and Esc buttons, select Serial Port Configuration mode.
• Select 38400 baud for the RS-232 Primary port in Serial Port Configuration mode
and indicate its selection.
h
Esc ( > ) button and LED — The Esc ( > ) button and LED have one primary function (❏)
and four secondary (•) functions:
❏
Cancels operations or selections in progress and resets the front panel LEDs and
flashes once to indicate that the escape function has been activated.
NOTE: The Esc ( > ) button does not reset the current configuration, the Video
button and Audio button selection, any presets, or any audio gain,
attenuation, or volume settings.
• Increase the audio level of the selected input in Audio mode.
• Increase the volume of the selected output in Audio mode.
• With the Enter, Preset, and View buttons, select Serial Port Configuration mode.
• Select 115200 baud for the RS-232 Primary port in Serial Port Configuration mode
and indicate its selection.
MPX 866 A Media Presentation Matrix Switcher • Operation 20
