Low resolution video group
The switcher can connect to up to as many as six S-video sources, composite video sources,
or both and output to as many as six video devices.
c
Video Input 9 and Video Input 10 (composite video inputs) — Connect
9
10
GENLOCK
VIDEO
VIDEO
composite video sources to these female BNC connectors.
NOTE: Video Input 9 serves as a timing reference for all other low
resolution video group inputs. If one of the inputs is synced to a
blackburst generator, connect that source to Video Input 9.
d
Video Input 11 through Video Input 14 —
11
Y /VID
C
S-video inputs — Connect an S-video source to a pair of female BNC
connectors. Connect luma (Y) and chroma (C) as shown at right.
Composite video inputs — Connect a composite video source to the Video
(top) connector in a pair of female BNC connectors as shown at right.
NOTE: The switcher must be set to accept video inputs 11 through 14
as either S-video or composite video. Composite video is the
default. See “
Selecting Composite Video or S-video ” on
page 39 to change the setting.
e
Composite video outputs (Video Output 7 and Video Output 8) —
7
Connect composite video displays to these female BNC connectors.
NOTE: If the input tied Video Output 7 or Video Output 8 is S-video, the
switcher encodes the input to composite video.
If the tied input is composite video, the switcher passes the
signal through to the output with no processing.
f
S-video outputs (Video Output 9 and Video Output 10) —
Y
C
9
Connect S-video displays to these female BNC connectors.
NOTE: If the input tied Video Output 9 or Video Output 10 is composite
video, the switcher decodes the input to S-video.
If the tied input is S-video, the switcher passes the signal through
to the output with no processing.
g
Pass-through outputs (Video Output 11 and Video Output 12) —
12
Y/VID
S-video Composite
video
C
11
Connect S-video or composite video displays to these female BNC
connectors. Connect S-video Y and C or composite video as shown at
right.
NOTE: The switcher passes the tied input to these outputs with no
signal processing; an S-video input is output as S-video, a
composite video input is output as composite video.
12
Y/ VID
C
MPX 866 A Media Presentation Matrix Switcher • Installation 8
