Command and Response Table for SIS Commands
Symbol Definitions
] = CR/LF (carriage return/line feed) (hex 0D 0A)
} = Carriage return (no line feed, hex 0D)
| = Pipe (can be used interchangeably with the
}
character)
• = Space character
E = Escape key (hex 1B)
NOTE: A video input from either of the two groups cannot be tied to an output in the other group.
Audio can be tied to any output, regardless of the video group to which it was input.
X! = Input number (for tie) 00 = untied
01 – 08 for the computer video group
09 – 14 for the low resolution video group
X@
= Output number 01 – 12 for video
01 – 06 for audio
X# = Input number 01 – 08 for the computer video group
09 – 14 for the low resolution video group
X$ = Input signal format 1 = composite video (default)
2 = S-video
X% = Mute status 0 = off, 1 = on
X^
= Volume adjustment range 00 – 64 (1 dB per step except for 0-to-1, which is 34.5 dB)
(
see the table on page 67)
X& = Numeric dB value –18 to +24 (45 steps of gain or attenuation) (default = 0)
X* = Audio gain 0 – 24 (1 dB per step)
X( = Audio attenuation 1 – 18 (1 dB per step)
X1) = Global preset # 32 maximum (0 = current configuration)
X1! = Video and audio mute: 0 = no mutes
1 = video mute
2 = audio mute
3 = video and audio mute
X1@ = Name (for global presets, inputs, and outputs) 12 characters maximum
Upper- and lower-case alphanumeric characters are valid.
NOTE: The following characters are invalid or not recommended in the name: ~ , @ ‘ [ ] { } < > ’ “ ; | \ and ?.
X1# = Signal detection 0 = no input detected, 1 = input detected)
X1$ = Firmware version number to second decimal place (x.xx)
X1% = Verbose firmware version-description-upload date/time (see page 71 ).
X1^ = Voltage Positive or negative voltage and magnitude
X1&
= Temperature Degrees Fahrenheit
X1* = Front panel locks (Executive modes) 0 = Mode 0 1 = Mode 1 2 = Mode 2
MPX 866 A Media Presentation Matrix Switcher • Programming Guide 64
