Page 70
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Create ties
NOTES: • The ! tie command for RGB and % tie command for video can be used interchangeably for ties within the same group.
• Video ties cannot be made between the computer video group and the low resolution video group.
• Video and audio ties between the low resolution video input subgroup and the low resolution video output subgroup are made
with the audio automatically redirected. In such an operation, the switcher automatically ties the audio to an output in the
computer video/audio outputs subgroup (outputs 1 through 6). See “
,” on page 24 to identify the
outputs to which audio inputs are tied.
• The matrix switcher supports 1- and 2-digit numeric entries (1*1 and 02*02).
• Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&3*03%.
• The quick multiple tie and tie input to all output commands activate all I/O switches simultaneously.
Tie input
X!
to output
X@
,
video and audio
X!
*
X@
!
Out
X@
•
In
X!
•
All
]
— or —
Qik
]
Tie the video and audio on input
X!
to output
X@
.
NOTE: The response is Out
X#
•In
X!
•All
]
when the video and audio ties are made between the computer video input group and the
computer/audio output group, because audio always follows the video.
The response is Qik
]
when video and audio ties are made between the low resolution video input group and the low resolution
video output group, because audio is automatically broken away to the computer/audio group.
Example (computer
video group tie):
1*3!
Out03
•
In01
•
All
]
Tie input 1 video and audio to output 3.
Example (low resolution
video group tie):
9*9!
Qik
]
Tie input 9 video to output 9. The switcher
automatically redirects the audio to output 3.
Tie input
X!
to output
X@
,
RGB (video) only
X!
*
X@
&
Out
X@
•
In
X!
•
RGB
]
Tie the video for input
X!
to output
X@
. Video
is broken away.
Example (see the 1st
bulleted note, above):
5*4&
Out04
•
In05
•
RGB
]
Tie input 5 RGB to output 4.
Tie input
X!
to output
X@
,
video only
X!
*
X@
%
Out
X@
•
In
X!
•
Vid
]
Tie the video for input
X!
to output
X@
. Video
is broken away.
Example (see the 1st
bulleted note, above):
9*7%
Out07
•
In09
•
Vid
]
Tie input 9 video to output 7.
Tie input
X!
to output
X@
,
audio only
X!
*
X@
$
Out
X@
•
In
X!
•
Aud
]
Tie the audio for input
X!
to output
X@
. Audio
is broken away.
NOTE: Audio ties can only be made to the computer video/audio subgroup (outputs 1 through 6). The switcher responds with an E13
error if you try to make an audio-only tie to outputs 7 through 12.
Example:
12*4$
Out04
•
In12
•
Aud
]
Tie input 12 audio to output 4.
Quick multiple tie
E
+Q
X!
*
X@
! ...
X!
*
X@
$
}
Qik
]
NOTE: All video and audio group rules apply to the quick multiple tie command.
Example:
E
+Q3*4!3*11%13*6$
}
Tie input 3 video and audio to output 4,
tie input 11 video to output 12,
and tie input 13 audio to output 6.
Qik
]
Command and Response Table for SIS Commands
NOTE:
X!
= Input number (for tie)
00 (untied)
01 – 08 for the computer video group
09 – 14 for the low resolution video group
X@
= Output number
01 – 12 for video
01 – 06 for audio
MPX 866 A Media Presentation Matrix Switcher • Programming Guide
65
