Page 18
Reset Button and LED
l
Reset button — The recessed Reset button initiates four different levels of
RESET
matrix switcher reset:
z
z
Events (mode 3) reset — Toggles events monitoring on and off.
z
z
IP settings (mode 4) reset — Reset the IP functions of the switcher.
NOTE: The IP settings reset does not replace any user-installed firmware.
z
z
Absolute (mode 5) reset — Restore the switcher to the default factory conditions.
z
z
Hard reset — Restore the switcher to the default factory conditions and return the
switcher to the default firware that shipped with the unit.
NOTES: • Factory loaded firmware is active until it is replaced or the power is
cycled.
• Hard reset does not clear the current configuration.
See “
Power
m
AC power connector — Plug a standard IEC power cord into this connector to connect
the switcher to a 100 VAC to 240 VAC, 50 or 60 Hz power source.
MPX 866 A Media Presentation Matrix Switcher • Installation
13
