Cables
When using signals with a scanning frequency of 15-125 kHz and running distances of 100
feet or more, use high resolution BNC cables to achieve maximum performance.
Bulk cable and termination tools
MHR mini high resolution cable Part Number
MHRVGA/1000 non-plenum 5-conductor, 1000' (300 m) 22-024-03
MHR-2/500 non-plenum 2-conductor, 500' (150 m) 22-123-03
MHR-2P/500 plenum 2-conductor, 500' (150 m) 22-129-03
RG6 super high resolution cable Part Number
RG6/500 non-plenum single-conductor, 500' (150 m) 22-098-02
RG6-1000 non-plenum single-conductor, 1000' (300 m) 22-098-03
RG6P/500 plenum single-conductor, 500' (150 m) 22-164-02
RG6P/1000 plenum single-conductor, 1000' (300 m) 22-164-03
Termination tools and connectors Part Number
15-pin HD connectors, (VGA style), qty. 10 100-070-51
CTU 300 four-in-one coax crimp termination tool 100-241-02
BNC male MHR crimp connectors, qty. 100 100-335-01
BNC male RG6 crimp connectors, qty. 100 100-339-01
CTU 100 universal compression tool (BNC, F, RCA) 100-181-01
MHR BNC compression kit (100 MHR BNC connectors) 60-538-01
RG6 BNC compression kit (100 RG6 BNC connectors) 60-538-02
MPX 866 A Media Presentation Matrix Switcher • Reference Information 124
