Button Labels
Figure 77 on page 128 provides blank button labels for 16-button switchers. Feel free to
photocopy them or cut them out of the guide, write button information in each button area
as desired, and put them in the label window of the switcher.
To remove a panel, insert the Phillips-head end of a Tweeker or small Phillips-head
screwdriver into the hole in one end of the panel, and gently slide the tab at the edge of the
panel out of the recess in the switcher housing.
Printing Instructions
If you print these strips to cut out and use in your switcher:
z
z
Print on A-size, 8-1/2 inch by 11 inch (letter) paper, in portrait orientation.
z
z
Set page scaling to None.
z
z
After printing, verify that the printed strips fit behind the panel. Your printer
configuration may cause the strip to be printed smaller or larger than specified.
MPX 866 A Media Presentation Matrix Switcher • Reference Information 127
