Command/Response Table for SIS Commands (continued)
Command ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Create ties (continued)
NOTES: • All video and audio group rules apply to all of the tie all commands listed below.
• The ! tie all command for RGB and % tie all command for video can be used interchangeably for ties within the same group.
Tie input to all outputs,
video and audio X! *! In X!
• All ]
Example: 5*! In05 • All ] Tie input 5 video and audio to all computer
video/audio group outputs only.
Example: 12*! In12 • All ] Tie input 12 video to all low resolution
video groups only. Tie input 12 audio to all
computer/audio group outputs only.
NOTE: 0*! clears all ties.
Tie input to all outputs,
RGB (video) only X! *& In X!
• RGB ] Video is broken away.
Example (see the 2nd
bulleted Note, above): 8*& In08 • RGB ] Tie input 8 RGB to all computer video group
outputs only.
Tie input to all outputs,
video only X! *% In X!
• Vid ] Video is broken away.
Example (see the 2nd
bulleted Note, above): 10*% In10 • Vid ] Tie input 10 video to all low resolution video
group outputs only.
Tie input to all outputs,
audio only X! *$ In X!
• Aud ] Audio is broken away.
Read ties
NOTES: • The ! read tie command for RGB and the % read tie command for video can be used interchangeably.
• When the switcher is in verbose mode 1 or 3, the response is Out X!
•In
X#
•(RGB), (Vid), or (Aud)
] .
Read tied input, RGB output X@ & X!] Input X! video is tied to output X@ .
Read tied input, Video
output X@ % X!] Input X! video is tied to output X@ .
Read tied input, audio
output X@ $ X!] Input X! audio is tied to output X@ .
Configure input format
Configure input as
composite video X# *1\ Typ X# *1 ] Define input X# as composite video.
Example: 11*1\ Typ11*1 ] Configurable input 11 is set as composite
video.
Configure input as S-video X# *2\ Typ X# *2 ] Define input X# as S-video.
View input configuration X# \ X$] Show the configuration of input X# .
Video mute commands
Video mute X@ *1B Vmt X@ *1 ] Mute output X@ video (video off).
Video unmute X@ *0B Vmt X@ *0 ] Unmute output X@ video (video on).
Read video mute status X@ B X%]
Global video mute 1*B Vmt1 ] Mute all video outputs.
Global video unmute 0*B Vmt0 ] Unmute all video outputs.
NOTE: X! = Input number (for tie) 00 (untied)
01 – 08 for the computer video group
09 – 14 for the low resolution video group
X@ = Output number 01 – 12 for video
01 – 06 for audio
X# = Input number 11 – 14 (the only valid inputs for the “/“ command)
X$ = Input signal format 1 = composite video 2 = S-video
X% = Mute status 0 = off 1 = on
MPX 866 A Media Presentation Matrix Switcher • Programming Guide 66
