E-10 Accel Time 2
Range: Function:
the output current does not exceed the current
limit in F-43 Current Limit during ramping. The
value 0.00 corresponds to 0.01 s in speed mode.
See decel time in E-11 Decel Time 2.
Par . E − 10 =
tacc s x ns RPM
ref RPM
E-11 Decel Time 2
Range: Function:
3.00
s *
[0.01
- 3600
s]
Enter the decel time from the rated motor speed
n
s
to 0 RPM. Choose a decel time such that no
over-voltage arises in the inverter due to
regenerative operation of the motor, and such
that the generated current does not exceed the
current limit set in F-43 Current Limit. The value
0.00 corresponds to 0.01 s in speed mode. See
accel time in E-10 Accel Time 2.
Par . E − 11 =
tdec s x ns RPM
ref RPM
E-12 Accel Time 3
Range: Function:
3.00 s * [0.01 -
3600 s]
Enter the accel time from 0 RPM to the rated
motor speed n
s
. Choose a accel time such
that the output current does not exceed the
current limit in F-43 Current Limit during
ramping. The value 0.00 corresponds to 0.01
s in speed mode. See decel time in
E-13 Decel Time 3.
E-13 Decel Time 3
Range: Function:
3.00
s *
[0.01
- 3600
s]
Enter the decel time from the rated motor speed
n
s
to 0 RPM. Choose a decel time such that no
over-voltage arises in the inverter due to
regenerative operation of the motor, and such
that the generated current does not exceed the
current limit set in F-43 Current Limit. The value
0.00 corresponds to 0.01 s in speed mode. See
accel time in E-12 Accel Time 3.
Par . E − 13 =
tdec s x ns RPM
ref RPM
E-14 Accel Time 4
Range: Function:
3.00
s *
[0.01 -
3600 s]
Enter the accel time from 0 RPM to the rated
motor speed n
s
. Choose a accel time such that
the output current does not exceed the current
limit in F-43 Current Limit during ramping. The
value 0.00 corresponds to 0.01 s in speed mode.
See decel time in E-15 Decel Time 4.
Par . E − 14 =
tacc s x ns RPM
ref RPM
E-15 Decel Time 4
Range: Function:
3.00
s *
[0.01
- 3600
s]
Enter the decel time from the rated motor speed
n
s
to 0 RPM. Choose a decel time such that no
over-voltage arises in the inverter due to
regenerative operation of the motor, and such
that the generated current does not exceed the
current limit set in F-43 Current Limit. The value
0.00 corresponds to 0.01 s in speed mode. See
accel time in E-14 Accel Time 4.
Par . E − 15 =
tdec s x ns RPM
ref RPM
3.4.3 E-2# Digital Output
Parameters to configure terminal 27 and 29 digital outputs
controlled by serial communications and to configure Relay
1 and Relay 2.
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
terminal 27 in E-51 Terminal 27 Mode, and set the I/O
function for terminal 29 in E-52 Terminal 29 Mode. These
parameters cannot be adjusted while the motor is running.
[0] No operation Default for all digital outputs and relay
outputs
[1] Control ready The control board receives supply
voltage.
[2] Drive ready The frequency converter is ready for
operation and applies a supply signal on
the control board.
[3] Drive ready /
remote control
The frequency converter is ready for
operation and is in Auto mode.
[4] Enable / no
warning
Ready for operation. No start or stop
command is been given (start/disable).
There are no warnings.
[5] Drive running Motor is running.
[6] Running / no
warning
Output speed is higher than the speed
set in H-81 Min Speed for Function at Stop
[RPM]. The motor is running and there
are no warnings.
[7] Run in range /
no warning
Motor is running within the programmed
current and speed ranges set in
H-70 Warning Current Low to
H-73 Warning Speed High. There are no
warnings.
[8] Run on
reference / no
warning
Motor runs at reference speed.
[9] Alarm An alarm activates the output. There are
no warnings.
[10] Alarm or
warning
An alarm or a warning activates the
output.
