LC-16 RS-FF Operand R
Option: Function:
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] Logic Controller Time-out 3
[71] Logic Controller Time-out 4
[72] Logic Controller Time-out 5
[73] Logic Controller Time-out 6
[74] Logic Controller Time-out 7
[75] Start command given
[76] Digital input x30 2
[77] Digital input x30 3
[78] Digital input x30 4
[90] ATEX OL cur. warning
[91] ATEX OL cur. alarm
[92] ATEX OL freq. warning
[93] ATEX OL freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
3.19.3 LC-2# Timers
Parameters to configure the Logic Controller (LC) timers.
Timers are used to define when an event can occur.
LC-20 Logic Controller Timer
Range: Function:
0.000 * [0.000 -
0.000]
Enter the value to define the duration of the
FALSE output from the programmed timer.
A timer is only FALSE if it is started by an
action (i.e. [29] Start timer 1) and until the
given timer value has elapsed.
3.19.4 LC-4# Logic Rules
Parameters to configure the Logic Controller (LC) Logic
Rules. Logic Rules are used to define what conditions need
to be met for the LC to step to the next event.
LC-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[0] * False Select the first boolean (TRUE or FALSE) input for the
selected logic rule.
See LC-01 Start Event ([0] - [61]) and LC-02 Stop Event
([70] - [75]) for further description.
LC-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the first logical operator to use on
the Boolean inputs from LC-40 Logic Rule
Boolean 1 and LC-42 Logic Rule Boolean 2.
[LC-##] signifies the boolean input of
parameter group LC-## Logic Controller.
[0] * DISABLED Ignores LC-42 Logic Rule Boolean 2,
LC-43 Logic Rule Operator 2, and LC-44 Logic
Rule Boolean 3.
[1] AND Evaluates the expression [LC-40] AND
[LC-42].
[2] OR Evaluates the expression [LC-40] OR [LC-42].
[3] AND NOT Evaluates the expression [LC-40] AND NOT
[LC-42].
[4] OR NOT Evaluates the expression [LC-40] OR NOT
[LC-42].
[5] NOT AND Evaluates the expression NOT [LC-40] AND
[LC-42].
[6] NOT OR Evaluates the expression NOT [LC-40] OR
[LC-42].
[7] NOT AND NOT Evaluates the expression NOT [LC-40] AND
NOT [LC-42].
[8] NOT OR NOT Evaluates the expression NOT [LC-40] OR
NOT [LC-42].
LC-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[0] * False Select the second boolean (TRUE or FALSE) input for
the selected logic rule. See LC-01 Start Event ([0] -
[61]) and LC-02 Stop Event ([70] - [75]) for further
description.
