2.1.7 Initial Commissioning
The easiest way of carrying out the initial commissioning is by pressing [Quick Menu] and following the quick set-up
procedure (read Table 2.3 from left to right). The example applies to open loop applications.
Press
Quick Start
K-01 Language Set language
K-02 Motor Speed Unit Set motor speed in Hz or RPM
P-02 Motor Power [HP] or P-07 Motor
Power [kW]
Set Motor nameplate power
F-05 Motor Rated Voltage Set Nameplate voltage
F-04 Base Frequency Set Nameplate frequency
P-03 Motor Current Set Nameplate current
P-06 Base Speed Set Nameplate speed in RPM
F-01 Frequency Setting 1 Set reference source
F-02 Operation Method Select which reference site to activate
F-07 Accel Time 1
Set the accel time with reference to synchronous motor
speed, n
s
F-08 Decel Time 1
Set the decel time time with reference to synchronous
motor speed, n s
F-10 Electronic Overload Set motor thermal protection
F-15 Motor Speed High Limit [Hz] or
F-17 Motor Speed High Limit [RPM]
Set motor speed high limit in Hz or RPM
F-16 Motor Speed Low Limit [Hz] or
F-18 Motor Speed Low Limit [RPM]
Set motor speed low limit in Hz or RPM
H-08 Reverse Lock Set allowed rotation direction
P-04 Auto Tune
Set desired auto tune function. Enable complete auto
tune is recommended
Table 2.3
