Replace Playback Mode
In this mode, you play the playlist back and insert the new section between the defined IN
and OUT points.
After you have selected the required settings for the Replace function, the Replace
Playback mode is automatically activated: the playlist is cued before the IN point (to
create guardbands), ready to be initiated.
The playlist is played at the speed defined in the playlist but the lever can also be used to
vary the playback speed.
When the Protect OUT point of the clip is reached, a clip containing the IN and OUT
points with the guardbands is created on the Receive page defined in the Setup menu.
The loop is stopped and the user switches back to match Frame Edit mode.
Methods
You can perform a Replace action in two ways:
• By defining an IN and OUT points in the Replace Edit mode.
• By defining only an IN point in the Replace Edit mode, and defining the OUT point
while you perform the Replace in the Replace Playback mode.
Warning
The IN and OUT points cannot be marked on a transition (including split audio
transitions and swap zones) or on a split zone (the key will flash red when it is
the case).
How to Perform a Replace
First define the Replace function in the Replace Edit mode. Then execute the Replace
function in the Replace Playback mode.
To perform a Replace, proceed as follows:
1. Open the playlist in which you want to replace a section in Playlist Edit mode.
2. In Playlist Edit mode, press Menu on the Remote Panel to access the secondary
menu.
3. Press the A key to enter the Replace Edit mode.
4. Use the jog dial to reach the desired IN point for the Replace section and press the IN
key to mark it.
When the IN point has been marked, the display switches to:
Cam A +2fields
Replace Int.Loop Ext.Loop
5. If you want to specify the OUT point for the Replace section at this stage, jog to the
requested point and press the OUT key. Otherwise, you can define the OUT point
while you perform the Replace.
The Int.Loop (B) and Ext.Loop (C) keys are blinking.
