Goto OUT
When you are in CLIP mode, this key combination enables the operator to go to IN / OUT
points of clips, instantly.
OUT
This function defines the OUT point of a clip. This operates similarly to the IN button.
Modification of Clip IN / OUT Points
Select the clip that you wish to modify, use the jog dial to position the material at the new
IN or OUT point, and re-mark the IN or OUT point(s) as required.
Warning
When IN/OUT points are set and a clip is saved, the system automatically
write-protects a user definable length of material before and after the IN/OUT
points respectively. These are referred to as the guardbands. Their duration can
be set with the Default clip duration parameter in the Operational Setup menu
(p.2.2 F2) as required.
Lever
This function is used to perform slow motion from 0 to 100% and to playback material from
100 to + 100% or from 200 to + 200% when Secondary Lever range is selected. The lever
has a continuous, linear range, except when Super Motion material is loaded on the
primary channel. In this case, there is a “flat step” at 33% (SD Super Motion) or 50% (HD
Super Motion) to help the operator locating easily the ideal playback speed.
Warning
When playing Super Motion material in slow motion, to obtain the smoothest
replay, it is important that the replay speed is exactly the ideal slow motion
speed, i.e. 33% for SD Super Motion or 50% for HD Super Motion. If the replay
speed is slightly off these ideal values, movements might appear staggered.
These ideal speeds can also be called directly by pressing the PLAY button
when the current element is Super Motion. The PGM speed and Var Max modes
can also be used to facilitate this. See Chapter 6 ‘PGM-PRV Mode’ on page 26
for a description on these modes.
