3.6.

Controlled and Primary Channels

Controlled Channel

A channel is "controlled" when the operator can control it with the jog dial. In this case, the
words "FULL CTRL" are present on the top of the OSD of the output monitor of that
channel.

Primary Channel

The primary channel is the first controlled channel. It is identified by stars around its name
on the OSD of the output monitor and on the LCD display of the Remote Panel (ex:
*PGM1*).

Examples:

In 1PGM+PRV mode with PRV CTRL OFF, the primary channel is PGM.

In 1PGM+PRV mode with PRV CTRL ON, the primary channel is PRV.
