2.2.5. Jog Dial
The jog dial allows the operator to pass into Search mode and thus to choose exactly the
Short OUT or Short IN image.
Move the jog dial clockwise to search forward and move it counter-clockwise to search
backwards. One revolution of the jog dial will produce a jump of approximately 35 frames.
When using the Fast mode, this number is multiplied by a factor defined in the Setup
menu.
Note
The jog dial is also used to:
• Set parameters in the Setup menu.
• Browse inside the clip database, the cue points or the current playlist. Refer
to the explanation of the Browse function for more details.
The jog dial is active at all times when the system is in Play and Record modes.
2.2.6. Lever
The lever is used to start a play or to modify the slow motion speed. Its run can be of two
different types depending on the lever mode. In standard mode, the lever run goes from 0
up to 100%.
Different ranges are available to play material from –400% to 400% using the 'Second
lever range' parameter in the Operational Setup menu (p.9.1 F5).
To access this second speed range, press SHIFT+Lever on the remote controller.
Note
When SD SUPER MOTION material is loaded on the primary channel, the lever
range has a larger, flat step at 33%.
In HD SUPER MOTION mode, the step is at 33% or 50% depending on the
camera.
The lever is also used to adjust speed, effect type, and duration in Playlist Edit mode.
