General Principles

Protect IN & Protect OUT points of a clip cannot be replaced by new ones.

Short IN & Short OUT points of a clip can be replaced by new ones.

Short OUT point is excluded. The clip freezes on previous field when playing back (with
post-roll mode disabled).

(Short) IN & OUT are always on even fields. This is automatic.

The guardband beyond the Short OUT point is created with the material available when
the operator saves the clip by pressing the selected F_ key. Therefore, this guardband can
sometimes be shorter than the value defined in the Setup menu.

4.1.2.

Clip Numbering Hierarchy

Introduction

Multicam can store up to 900 (multiplied by the number of cameras) clips and 100 playlists
in its libraries. 900 clips with up to 6 camera angles per clip result in 5400 clips on a server.
This number is displayed in the upper right window of the VGA Setup screen (SHIFT+F2
from the PC keyboard).

32

4. Clip Management

EVS Broadcast Equipment S.A.

Issue 11.02.A July 2013
