Extended View
The extended view shows cameras A to F instead of A to D. Only 1 bank can be viewed at
a time. The switch between standard and extended view is done by pressing F5 on the
keyboard or by clicking on the “F5:VIEW” area on the screen.
Title Bar
The Title bar contains the status information:
• Name of the EVS server.
• Total number of clips (1 camera angle counting for 1 clip in this count).
• Total duration of all clips.
• Remaining capacity on the server (all record trains together; valid for local server
only).
Clip Information Area
The next area is the Clip Information Area which displays the clips of the selected page
and bank(s). Two clip banks are displayed at a time.
