Pref
Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref
Selecting this function enables the Preference mode.
See section "Preference Mode (PREF)" on page 29 for more inforamtion on this option.
Aud.Met.
Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref
This option enables/disables the display of audio meters for all channels using the OSD of
the output monitors.
Post-Roll
Aud.Met. PgmSpd PostRoll
Mix. Sw to IN Pref
When the post-roll mode is enabled, that function is highlighted on the LCD and a “P”
appears on the OSD of the output monitors.
When the user exits Multicam with the post-roll mode on, this mode will still be enabled
when Multicam is restarted.
The post-roll mode works as follows depending on the element played:
• When a clip is played, it will not stop on the Short OUT point, but will continue to play
through the Short OUT point by the post-roll duration defined in the Setup Menu.
• When a record train is played, the same will happen if the Record trains OUTs
parameter is set to “Freeze” in the Operational Setup menu (p.2.3 F1).
• When a playlist is played, the post-roll will apply only to the last clip of the playlist.
3.2.4. Full Control and Lever Control
You control both PGM and PRV when the PRV CTL key is not active.
Once you select PRV CTL, you gain control on the PRV channel with the jog dial and
most keys, while the lever and the PLAY key control the PGM output. At this point,
selecting clips will call them up on the PRV channel.
Activating both the PRV CTL and the SW to IN functions allows the operator to auto-chain
cameras from the same IN point.
