2.3. Remote Panel Operations
2.3.1. Main Menu
Introduction
After the boot sequence of the Multicam system, the LCD screen of the Remote Panel
will display the Main menu:
2Rec 2Play Server Ver:11.00.xx
F1: 1 Remote F6: Exit
F2: 2 Remotes F7: Clear all clips
F3: F8: Stop Record
F4: F9: Fill Playlist
F5: Char. On/Off F0: Technical setup
Setup
1PGM+PRV 2 PGM
The Main menu has special function key operations as shown above, as well as the “soft”
keys options to enter 1PGM, 1PGM+PRV, or 2PGM modes (if available) and to enter the
Setup menu to configure your remote controller or to add special functions to your
application.
Note
If 2 channels are available for the first Remote Panel, the B key will display 2
PGM.
Returning to the Main Menu
From any section of the application, except Playlist mode, press SHIFT+MENU on the
first Remote Control panel to return to the main menu.
Function Keys in the Main Menu
Select the corresponding Function key (F_ key), and then press ENTER to validate the
selection.
Function Key Use
F1 to F4 If desired, the Multicam system can be run using 1 or 2 EVS
Remote Panels. Depending on the number of play channels
available in the current configuration, 1- or 2- Remote modes will
be available from the main menu.
F1: 1 Remote One Remote Panel is used in the configuration
F2: 2 Remotes Two Remote Panels are used in the configuration.
