5.7.3. Using the Replace Function
Introduction
The purpose of the Replace function is to consolidate the effects defined on a playlist as
follows:
The operator loops a section or an entire playlist back to themselves and, during the
playback, add some effects externally (graphic insertion for instance) or internally
(changing the speed).
While the operator plays the playlist back, and inserts the requested effects, the playback
result is re-injected into the playlist from a predefined IN frame. The OUT point of the
replaced section is predefined or manually defined in the record process.
The Replace function is only available on the Remote Panel.
Note
The Replace function is not allowed on playlists containing growing clips.
Accessing the Replace Function
Press MENU in Playlist Edit mode to open the secondary menu with the Replace
function. Select Replace in this menu to access the Replace function :
Clr Unav OtherAng
Replace Redo Undo
Replace Edit Mode
This mode allows to specify the following information for the Replace:
• IN point and OUT point, for the section to replace in the playlist. The OUT point can
also be defined during the Replace itself.
• Loop mode parameters.
In the Replace Edit mode, the playlist is considered as one entity on which you can mark
one IN point and one OUT point (pressing the IN and OUT points does not retrim the
current playlist clip).
Those IN and OUT points will be used to determine what portion of the playlist will be
replaced.
