Chapter 3 Status Screens
NWA3550 User’s Guide
49
Status This field indicates whether or not the ZyXEL Device is using the interface.
For each interface, this field displays Up when the ZyXEL Device is using
the interface and Down when the ZyXEL Device is not using the interface.
Rate For the LAN port this displays the port speed and duplex setting.
For the WLAN1 and WLAN2 interfaces, it displays the downstream and
upstream transmission rate or N/A if the interface is not in use.
SSID Status
Interface This column displays each of the ZyXEL Device’s wireless interfaces,
WLAN1 and WLAN2.
SSID This field displays the SSID(s) currently used by each wireless module.
BSSID This field displays the MAC address of the wireless adaptor.
Security This field displays the type of wireless security used by each SSID.
VLAN This field displays the VLAN ID of each SSID in use, or Disabled if the
SSID does not use VLAN.
System Status
Show Statistics Click this link to view port status and packet specific statistics. See Section
18.2.1 on page 222 .
Association List Click this to see a list of wireless clients currently associated to each of the
ZyXEL Device’s wireless modules. See Section 18.3 on page 223 .
Channel Usage Click this to see which wireless channels are currently in use in the local
area. See Section 18.4 on page 224 .
Logs Click this to see a list of logs produced by the ZyXEL Device. See Section
16.1 on page 195 .
Rogue AP List Click this to see a list of unauthorized access points in the local area. See
Section 12.3.3 on page 149 .
Table 1 The Status Screen
LABEL DESCRIPTION
