Chapter 9 MBSSID and SSID
NWA3550 User’s Guide
122
The switch adds PVID (Port VLAN IDentity) tags to incoming frames that don’t already have
tags (on switch ports where PVID is enabled).
Figure 65 Multiple BSS with VLAN Example
9.1.5 Configuring Multiple BSSs
Click WIRELESS > Wireless and select MBSSID in the Operating Mode drop-down list
box to display the screen as shown.
LAN 1
LAN 2
BSS 1
BSS 2
PORT 1
PVID: ON
PORT 3
PVID: OFF
PORT 2
PVID: OFF
VLAN 2
VLAN 1
