Chapter 17 VLAN
NWA3550 User’s Guide
207
The following table describes the labels in this screen.
17.2.3 Configuring Management VLAN Example
This section shows you how to create a VLAN on an Ethernet switch.
By default, the port on the ZyXEL Device is a member of the management VLAN (VLAN ID
1). The following procedure shows you how to configure a tagged VLAN.
"
Use the out-of-band management port or console port to configure the switch if
you misconfigure the management VLAN and lock yourself out from
performing in-band management.
On an Ethernet switch, create a VLAN that has the same management VLAN ID as the
ZyXEL Device. The following figure has the ZyXEL Device connected to port 2 of the switch
and your computer connected to port 1. The management VLAN ID is ten.
Table 71 RADIUS VLAN
LABEL DESCRIPTION
Block station if
RADIUS server
assigns VLAN name
error!
Select this to have the ZyXEL Device forbid access to wireless clients when
the VLAN attributes sent from the RADIUS server do not match a configured
Name field.
When you select this check box, only users with names configured in this
screen can access the network through the ZyXEL Device.
VLAN Mapping Table Use this table to map names to VLAN IDs so that the RADIUS server can
assign each user or user group a mapped VLAN ID. See your RADIUS server
documentation for more information on configuring VLAN ID attributes.
See
Section 17.2.4 on page 210 for more information.
Index This is the index number of the VLAN mapping profile.
Active Select a check box to enable the VLAN mapping profile.
VLAN ID Type a VLAN ID. Incoming traffic from the WLAN is authorized and assigned
a VLAN ID before it is sent to the LAN.
Name Type a name to have the ZyXEL Device check for specific VLAN attributes on
incoming messages from the RADIUS server. Access-accept packets sent by
the RADIUS server contain VLAN related attributes. The configured Name
fields are checked against these attributes. If a configured Name field
matches these attributes, the corresponding VLAN ID is added to packets
sent from this user to the LAN.
If the VLAN-related attributes sent by the RADIUS server do not match a
configured Name field, a wireless station is assigned the wireless VLAN ID
associated with its SSID (unless the Block station if RADIUS server
assigns VLAN error! check box is selected).
Apply Click Apply to save your changes to the ZyXEL Device.
Reset Click Reset to begin configuring this screen afresh.
