Chapter 18 Maintenance
NWA3550 User’s Guide
223
The following table describes the labels in this screen.
18.3 Association List
View the wireless stations that are currently associated with the ZyXEL Device in the
Association List screen.
Click MAINTENANCE > Association List to display the screen as shown next.
Table 74 System Status: Show Statistics
LABEL DESCRIPTION
Port This is the Ethernet port (LAN) or wireless LAN adaptor (WLAN1 or WLAN2).
Status This shows the port speed and duplex setting if you are using Ethernet
encapsulation for the Ethernet port. Ethernet port connections can be in half-
duplex or full-duplex mode. Full-duplex refers to a device's ability to send and
receive simultaneously, while half-duplex indicates that traffic can flow in only
one direction at a time. The Ethernet port must use the same speed or duplex
mode setting as the peer Ethernet port in order to connect.
This shows the transmission speed only for the wireless adaptors.
TxPkts This is the number of transmitted packets on this port.
RxPkts This is the number of received packets on this port.
Collisions This is the number of collisions on this port.
Tx B/s This shows the transmission speed in bytes per second on this port.
Rx B/s This shows the reception speed in bytes per second on this port.
Up Time This is total amount of time the line has been up.
WLAN1 This section displays only when wireless LAN adaptor WLAN1 is in AP+Bridge
or Bridge/Repeater mode.
WLAN2 This section displays only when wireless LAN adaptor WLAN2 is in AP+Bridge
or Bridge/Repeater mode.
Index This is the index number of the bridge connection.
Remote Bridge MAC This is the MAC address of the peer device in bridge mode.
Status This shows the current status of the bridge connection, which can be Up or
Down.
TxPkts This is the number of transmitted packets on the wireless bridge.
RxPkts This is the number of received packets on the wireless bridge.
Poll Interval(s) Enter the time interval for refreshing statistics.
Set Interval Click this button to apply the new poll interval you entered above.
Stop Click this button to stop refreshing statistics.
