Page 37
Chapter 1 Introducing the ZyXEL Device
NWA3550 User’s Guide
37
Figure 5 Multiple BSSs
1.2.5 Pre-Configured SSID Profiles
The ZyXEL Device has two pre-configured SSID profiles.
1 VoIP_SSID. This profile is intended for use by wireless clients requiring the highest
QoS (Quality of Service) level for VoIP (Voice over IP) telephony and other applications
requiring low latency. The QoS level of this profile is not user-configurable. See
2 Guest_SSID. This profile is intended for use by visitors and others who require access
to certain resources on the network (an Internet gateway or a network printer, for
example) but must not have access to the rest of the network. Layer 2 isolation is enabled
(see
), and QoS is set to NONE. Intra-BSS traffic blocking is
). These fields are all user-configurable.
1.2.6 Configuring Dual WLAN Adaptors
The ZyXEL Device is equipped with dual wireless adaptors. This means you can configure
two different wireless networks to operate simultaneously.
In the following example, the ZyXEL Device (Z) uses WLAN1 in Access Point mode to
allow IEEE 802.11b and IEEE 802.11g clients to access the wired network, and WLAN2 in
AP+Bridge mode to allow an IEEE 802.11a AP to communicate with the wired network.
Internet
LAN
VoIP_SSID
SSID03
Guest_SSID
