241 power over ethernet (poe) specifications – ZyXEL Communications NWA3550 User Manual
Page 241
Chapter 20 Product Specifications
NWA3550 User’s Guide
241
Power over Ethernet (PoE) Specifications
You can use a power over Ethernet injector to power this device. The injector must comply to IEEE
802.3af.
Table 83 Power over Ethernet Injector Specifications
Power Output
15.4 Watts maximum
Power Current
400 mA maximum
Table 84 Power over Ethernet Injector RJ-45 Port Pin Assignments
PIN NO
RJ-45 SIGNAL
ASSIGNMENT
1
Output Transmit Data +
2
Output Transmit Data -
3
Receive Data +
4
Power +
5
Power +
6
Receive Data -
7
Power -
8
Power -
1 2 3 4 5 6 7 8
