Chapter 3 Status Screens
NWA3550 User’s Guide
48
System Information
System Name This field displays the ZyXEL Device system name. It is used for
identification. You can change this in the System > General screen’s
System Name field.
Model This field displays the ZyXEL Device’s exact model name.
Firmware Version This field displays the current version of the firmware inside the device. It
also shows the date the firmware version was created. You can change the
firmware version by uploading new firmware in Maintenance > F/W
Upload.
System Up Time This field displays the elapsed time since the ZyXEL Device was turned on.
Current Date Time This field displays the date and time configured on the ZyXEL Device. You
can change this in the System > Time Setting screen.
WLAN1 Operating
Mode
This field displays the current operating mode of the first wireless module
(AP, Bridge / Repeater, AP + Bridge or MBSSID). You can change the
operating mode in the Wireless > Wireless screen.
WLAN2 Operating
Mode
This field displays the current operating mode of the second wireless
module (AP, Bridge / Repeater, AP + Bridge or MBSSID). You can change
the operating mode in the Wireless > Wireless screen.
Management VLAN This field displays the management VLAN ID if VLAN is active, or Disabled
if it is not active. You can enable or disable VLAN, or change the
management VLAN ID, in the VLAN > Wireless VLAN screen.
IP This field displays the current IP address of the ZyXEL Device on the
network.
LAN MAC This displays the MAC (Media Access Control) address of the ZyXEL
Device on the LAN. Every network device has a unique MAC address which
identifies it across the network. Your ZyXEL Device features dual wireless
module, and has two MAC addresses. The MAC address of the first
wireless module (WLAN1) is used on the LAN.
WLAN1 MAC This displays the MAC address of the first wireless module.
WLAN2 MAC This displays the MAC address of the second wireless module.
System Resources
Flash This field displays the amount of the ZyXEL Device’s flash memory
currently in use. The flash memory is used to store firmware and SSID
profiles.
Memory This field displays what percentage of the ZyXEL Device’s volatile memory
is currently in use. The higher the memory usage, the more likely the ZyXEL
Device is to slow down. Some memory is required just to start the ZyXEL
Device and to run the web configurator.
CPU This field displays what percentage of the ZyXEL Device’s processing
ability is currently being used. The higher the CPU usage, the more likely
the ZyXEL Device is to slow down.
WLAN1 Associations This field displays the number of wireless clients currently associated with
the first wireless module. Each wireless module supports up to 128
concurrent associations.
WLAN2 Associations This field displays the number of wireless clients currently associated with
the second wireless module. Each wireless module supports up to 128
concurrent associations.
Interface Status
Interface This column displays each interface of the ZyXEL Device.
Table 1 The Status Screen
LABEL DESCRIPTION
