Chapter 5 System Status and Port Statistics
VES-1616F-3x Series User’s Guide
60
The following table describes the labels in this screen.
Table 8 Status: Port Details
LABEL
DESCRIPTION
Port Info
Link
This field displays the speed (either 10M for 10Mbps, 100M for 100Mbps or 1000M for
1000Mbps) and the duplex (F for full duplex or H for half duplex). It also shows the
cable type (Copper or Fiber) for the combo ports.
Status
If STP (Spanning Tree Protocol) is enabled, this field displays the STP state of the port
If STP is disabled, this field displays FORWARDING if the link is up, otherwise, it
displays STOP.
LACP
This field shows if LACP is enabled on this port or not.
TxPkts
This field shows the number of transmitted frames on this port
RxPkts
This field shows the number of received frames on this port
Errors
This field shows the number of received errors on this port.
Tx KB/s
This field shows the number kilobytes per second transmitted on this port.
Rx KB/s
This field shows the number of kilobytes per second received on this port.
Up Time
This field shows the total amount of time the connection has been up.
Tx Packet
The following fields display detailed information about packets transmitted.
TX
Packets
This field shows the number of good packets (unicast, multicast and broadcast)
transmitted.
Multicast
This field shows the number of good multicast packets transmitted.
Broadcast
This field shows the number of good broadcast packets transmitted.
Pause
This field shows the number of 802.3x Pause packets transmitted.
Rx Packet
The following fields display detailed information about packets received.
RX
Packets
This field shows the number of good packets (unicast, multicast and broadcast)
received.
Multicast
This field shows the number of good multicast packets received.
Broadcast
This field shows the number of good broadcast packets received.
Pause
This field shows the number of 802.3x Pause packets received.
Control
This field shows the number of control packets received (including those with CRC
error) but it does not include the 802.3x Pause packets.
TX Collision
The following fields display information on collisions while transmitting.
Single
This is a count of successfully transmitted packets for which transmission is inhibited
by exactly one collision.
Multiple
This is a count of successfully transmitted packets for which transmission was
inhibited by more than one collision.
Excessive
This is a count of packets for which transmission failed due to excessive collisions.
Excessive collision is defined as the number of maximum collisions before the
retransmission count is reset.
Late
This is the number of times a late collision is detected, that is, after 512 bits of the
packets have already been transmitted.
