VES-1616F-3x Series User’s Guide
259
C
H A P T E R
34
IEEE 802.1Q Tagged VLAN
Commands
This chapter describes the IEEE 802.1Q Tagged VLAN and associated commands.
34.1 Configuring Tagged VLAN
for background information on VLANs.
The following procedure shows you how to configure tagged VLAN.
1 Use the IEEE 802.1Q tagged VLAN commands to configure tagged VLAN for the
switch.
• Use the
vlan
command to configure or create a VLAN on the switch. The
switch automatically enters the
config-vlan
mode. Use the
inactive
command to
deactivate the VLAN(s).
• Use the
interface port-channel
to enter the config-
interface mode to set the VLAN settings on a port, then use the pvid
command to set the VLAN ID you created for the port-list to that specific port in the PVID
table.
• Use the
exit
command when you are finished configuring the VLAN.
Example:
2 Configure your management VLAN.
• Use the
vlan
command to create a VLAN (VID 3 in this example) for
managing the switch, and the switch will activate the new management VLAN.
• Use the
inactive
command to disable the new management VLAN.
sysname(config)# vlan 2000
sysname(config-vlan)# name up1
sysname(config-vlan)# fixed 10-12
sysname(config-vlan)# no untagged 10-12
sysname(config-vlan)# exit
sysname(config)# interface port-channel 10-12
sysname(config-interface)# pvid 2000
sysname(config-interface)# exit
