VES-1616F-3x Series User’s Guide
191
C
H A P T E R
27
Diagnostic
This chapter explains the Diagnostic screen.
27.1 Diagnostic
Click Management > Diagnostic in the navigation panel to open this screen. Use this screen
to check system logs, reset the system or ping IP addresses.
Figure 97 Diagnostic
The following table describes the labels in this screen.
Table 68 Diagnostic
LABEL DESCRIPTION
System Log Click Display to display a log of events in the multi-line text box.
Click Clear to empty the text box and reset the syslog entry.
IP Ping Type the IP address of a device that you want to ping in order to test a connection.
Click Ping to have the switch ping the IP address (in the field to the left).
Port Test From the Port drop-down list box, select a port number and click Internal Test to
perform internal loopback test or click External Test (on VDSL ports) to perform
loopback test to the remote devices.
