VES-1616F-3x Series User’s Guide

111

C

H A P T E R

13

Mirroring

This chapter shows you how to configure mirroring on the switch.

13.1 Mirroring Overview

Port mirroring allows you to copy a traffic flow to a monitor port (the port you copy the traffic
to) in order that you can examine the traffic from the monitor port without interference.

13.2 Port Mirroring Configuration

Click Advanced Application > Mirroring in the navigation panel to display the
configuration screen.
Use this screen to select a monitor port and specify the traffic flow to be copied to the monitor
port

Figure 41 Mirroring
