Chapter 13 Mirroring
VES-1616F-3x Series User’s Guide
112
The following table describes the related labels in this screen.
Table 30 Mirroring
LABEL DESCRIPTION
Active Clear this check box to deactivate port mirroring on the switch.
Monitor
Port
The monitor port is the port you copy the traffic to in order to examine it in more detail
without interfering with the traffic flow on the original port(s). Select this port from this
drop-down list box.
Port This field displays the port number.
Mirrored Select this option to mirror the traffic on a port.
Direction Specify the direction of the traffic to mirror. Choices are Egress (outgoing), Ingress
(incoming) and Both.
Apply Click Apply to save the changes.
Cancel Click Cancel to start configuring the screen again.
