Chapter 18 Classifier
VES-1616F-3x Series User’s Guide
130
The following table shows some other common Ethernet types and the corresponding protocol
number.
Some of the most common protocol port numbers are:
18.3 Classifier Example
The following screen shows an example where you configure a classifier that identifies all
traffic from MAC address 00:50:ba:ad:4f:81 on port 2.
After you have configured a classifier, you can configure a policy (in the Policy screen) to
define action(s) on the classified traffic flow.
Name This field displays the descriptive name for this rule. This is for identification purpose
only.
Rule This field displays a summary of the classifier rule’s settings.
Delete Click Delete to remove the selected entry from the summary table.
Cancel Click Cancel to clear the Delete check boxes.
Table 41 Common Ethernet Type Number
Ethernet Type number
IP ETHII 0800
X.75 Internet 0801
NBS Internet 0802
ECMA Internet 0803
Chaosnet 0804
X.25 Level 3 0805
XNS Compat 0807
Banyan Systems 0BAD
BBN Simnet 5208
IBM SNA 80D5
AppleTalk AARP 80F3
Table 42 Common Protocol Port Number
PORT NUMBER NAME
21 FTP
23 Telnet
25 SMTP
53 DNS
80 HTTP
110 POP3
Table 40 Classifier (continued)
LABEL DESCRIPTION
