Chapter 5 System Status and Port Statistics
VES-1616F-3x Series User’s Guide
54
The following table describes the labels in this screen.
5.2.1 VDSL Summary
To view VDSL statistics, click VDSL Summary in the Status screen.
Table 6 Status
LABEL DESCRIPTION
System up
Time
This field shows how long the system has been running since the last time it was
started.
The following fields are related to the VDSL ports.
Port This identifies the VDSL port. Click a port number to display the VDSL Port Details
screen.
PayLoad Rate This field displays the upstream and downstream payload rates.
State This field shows whether the port is connected (Showtime), not enabled (Idle) or is
negotiating a connection (Training).
Tx KB/s This field shows the number of kilobytes per second transmitted on this port.
Rx KB/s This field shows the number of kilobytes per second received on this port.
Up Time This field shows the total amount of time in hours, minutes and seconds the port has
been up.
Retrain Click Retrain to re-establish the line connection.
The following fields are related to the Ethernet ports.
Port This identifies the port. Click a port number to display the Port Details screen.
Link This field displays the speed (10M for 10Mbps, 100M for 100Mbps or 1000M for
1000Mbps) and the duplex (F for full duplex or H for half duplex).
State This field displays the STP state of the port. See the Spanning Tree Protocol chapter
for details on STP port states.
LACP This fields displays whether the Link Aggregation Control Protocol (LACP) has been
enabled on the port.
TxPkts This field shows the number of transmitted frames on this port.
RxPkts This field shows the number of received frames on this port.
Errors This field shows the number of received errors on this port.
Tx KB/s This field shows the number of kilobytes per second transmitted on this port.
Rx KB/s This field shows the number of kilobytes per second received on this port.
Up Time This field shows the total amount of time in hours, minutes and seconds the port has
been up.
Poll Interval(s) The text box displays how often (in seconds) this screen refreshes. You may change
the refresh interval by typing a new number in the text box and then clicking Set
Interval.
Stop Click Stop to halt system statistics polling.
Clear Counter Select ALL in the Port field and then click Clear Counter to erase the recorded
statistical information for all ports.
Otherwise, select a port from the Port drop-down list box and then click Clear
Counter to erase the recorded statistical information for that port.
