ZyXEL Communications VDSL SWITCH VES-1616F-3X - Manual (Page 234)

Chapter 32 Introducing the Commands
VES-1616F-3x Series User’s Guide
234
exit Exits from the interface port-channel
command mode.
13
flow-control Enables interface flow control. Flow
control regulates transmissions to
match the bandwidth of the receiving
port.
13
frame-type
ntagged>
Choose to accept both tagged and
untagged incoming frames or just
tagged incoming frames on a port.
13
gvrp Enables this function to permit VLAN
groups beyond the local switch.
13
help Displays a description of the interface
port-channel commands.
13
igmp-
filtering
profile Applies the specified IGMP filtering
profile.
13
igmp-group-
limit
Enables the IGMP group limiting
feature.
13
number Sets the maximum number IGMP
groups allowed.
13
igmp-
immediate-
leave
Enables the IGMP immediate leave
function.
13
igmp-querier-
mode
dge>
Sets the IGMP querier mode of a port.
auto uses the port as an IGMP query
port after it receives IGMP query
packets. fixed always uses the port
as an IGMP query port. edge stops
the switch from using the port as an
IGMP query port.
13
inactive Disables the specified port(s) on the
switch.
13
ingress-check Enables the device to discard
incoming frames for VLANs that are
not included in a port member set.
13
intrusion-
lock
Enables intrusion lock on a port and a
port cannot be connected again after
you disconnected the cable.
13
mirror Enables port mirroring on the port(s). 13
dir
h>
Enables port mirroring for incoming,
outgoing or both incoming and
outgoing traffic.
Port mirroring copies traffic from one
or all ports to another or all ports for
external analysis.
13
multicast-
limit
Enables the port(s) multicast limit. 13
Sets how many multicast packets the
port(s) receives per second.
13
name
name-string>
Sets a name for the port(s). Enter a
descriptive name (up to nine printable
ASCII characters).
13
Table 82 interface port-channel Commands (continued)
COMMAND DESCRIPTION P
