Xerox 490 - Manual (Page 188)

Resource Management Xerox 490/980 Color Continuous Feed Printing System
10-32 Printer & PC GUI Guide
Import a Resource File
A resource file can be imported from the removable media. Insert a removable media to the
drive, and select [Removable Disk] from the pull-down menu at Save to. Select the file to be
imported and select [Import] to display the Import screen.
• Close: Cancels the operation.
• OK: Imports the resource file.
Import TIFF File
The following screen is shown when importing a .tif or .tiff file. Select [Pre-printed Form] or
[Print Mark] for the file to be imported.
• Close: Cancels the operation.
• OK: Imports the resource file.
• Pre-printed Form: Selected when the file to be imported is the pre-printed form.
• Print Mark: Selected when the file to be imported is the print mark.
• Apply All: If two files or more are imported, the selection made above is applied to all of
them. If this item is not selected, either of the items above has to be selected for each file.
Note
The list in the disk displays the .forms, .tif and .tiff files. .imp files are not displayed.
