Xerox 490/980 Color Continuous Feed Printing System Gateway
Printer & PC GUI Guide 9-3
PC-GUI Gateway
Select [Gateway...] from the Setting menu to open the Gateway Setting dialog box.
Configure the Gateway
You can set one of three types of connection in the Gateway Setting dialog box, as follows.
1. FTP: You can configure the gateway to connect to the printer by FTP.
2. LPR: You can configure the gateway to connect to the printer by LPR.
3. IPDS: This is displayed where the IPDS option is installed.
IPDS attachment
Attachment information display No Yes Yes
Add attachment information No Yes Yes
Modify attachment information No Yes Yes
Delete attachment information No Yes Yes
Browse attachment information No Yes Yes
Select attachment information No Yes Yes
Eject status No Yes Yes
Function
Logon level
General User Operator
System
Administrator
