Page 65
65
Creating a Rhythm Set
For details regarding effect settings, refer to the pages shown below.
•
•
Making Multi-Effects Settings (MFX1–3)
•
•
Parameter Group [F6 (OUTPUT)]
Output Settings
Parameter
Value
Explanation
Rhythm Out Assign
MFX,
A, B,
1–4,
TONE
Specifies for each rhythm set how the direct sound will be output.
MFX:
Output in stereo through multi-effects. You can also apply chorus or reverb to the sound that passes
through multi-effects.
A, B:
Output to the OUTPUT A (MIX) jacks or OUTPUT B jacks in stereo without passing through multi-
effects.
1–4:
Output to the INDIVIDUAL 1–4 jacks in mono without passing through multi-effects.
TONE:
Outputs according to the settings for each rhythm tone.
* If you’ve made settings so that sounds are separately routed to the INDIVIDUAL 1 jack and INDIVIDUAL 2 jack, but
no plug is actually inserted in the INDIVIDUAL 2 jack, the sounds routed to INDIVIDUAL 1 and INDIVIDUAL 2
will be mixed and output from the INDIVIDUAL 1 jack.
Tone Out Assign
MFX,
A, B,
1–4
Specifies how the direct sound of each rhythm tone will be output.
MFX:
Output in stereo through multi-effects. You can also apply chorus or reverb to the sound that passes
through multi-effects.
A, B:
Output to the OUTPUT A (MIX) jacks or OUTPUT B jacks in stereo without passing through multi-
effects.
1–4:
Output to the INDIVIDUAL 1–4 jacks in mono without passing through multi-effects.
* If the Rhythm Out Assign is set to anything other than “TONE,” these settings will be ignored.
* If you’ve made settings so that sounds are separately routed to the INDIVIDUAL 1 jack and INDIVIDUAL 2 jack, but
no plug is actually inserted in the INDIVIDUAL 2 jack, the sounds routed to INDIVIDUAL 1 and INDIVIDUAL 2
will be mixed and output from the INDIVIDUAL 1 jack.
* If the Mix/Parallel parameter is set to “MIX,” all sounds are output from the OUTPUT A (MIX) jacks in stereo (p. 194).
* If you’ve set Tone Out Assign to “MFX,” set the MFX Output Assign parameter (p. 159) to specify the output desti-
nation of the sound that has passed through the multi-effects.
* Sounds are output to chorus and reverb in mono at all times.
* The output destination of the signal after passing through the chorus is set with the Chorus Output Select and Chorus
Output Assign parameters (p. 159).
* The output destination of the signal after passing through the reverb is set with the Reverb Output Assign parameter
Tone Out Level
0–127
Level of the signal that is sent to the output destination specified by Tone Output Assign
Send Level (Output = MFX)
Tone Chorus Send
0–127
Level of the signal sent to chorus for each rhythm tone if the tone is sent through MFX
Tone Reverb Send
0–127
Level of the signal sent to reverb for each rhythm tone if the tone is sent through MFX
Send Level (Output = non MFX)
Tone Chorus Send
0–127
Level of the signal sent to chorus for each rhythm tone if the tone is not sent through MFX
Tone Reverb Send
0–127
Level of the signal sent to reverb for each rhythm tone if the tone is not sent through MFX
Setting Effects for a Patch (Effects/MFX/MFX Control/Chorus/Reverb)
