Roland Fantom-Xa - Manual (Page 198)

198
Settings Common to All Modes (System Function)
[F2 (TX)]
[F3 (RX)]
[F4 (MMC MTC)]
Parameter Value Explanation
Transmit Program
Change OFF, ON Specifies whether Program Change messages will be transmitted (ON) or not (OFF).
Transmit Bank Se-
lect OFF, ON Specifies whether Bank Select messages will be transmitted (ON) or not (OFF).
Transmit Active
Sensing OFF, ON Specifies whether Active Sensing messages will be transmitted (ON) or not (OFF).
Transmit Edit Data OFF, ON Specify whether changes you make in the settings of a patch, performance will be transmitted
as system exclusive messages (ON), or will not be transmitted (OFF).
Soft Through OFF, ON Thru function re-transmits all messages received at the MIDI IN connector to the MIDI OUT
connector without modifying them in any way.
Parameter Value Explanation
Receive Program
Change OFF, ON Specifies whether Program Change messages will be received (ON) or not (OFF).
Receive Bank Select OFF, ON Specifies whether Bank Select messages will be received (ON) or not (OFF).
Receive Exclusive OFF, ON Specifies whether System Exclusive messages will be received (ON) or not (OFF).
Receive GM System
On OFF, ON Specifies whether General MIDI System On messages will be received (ON) or not (OFF).
Receive GM2 Sys-
tem On OFF, ON Specifies whether General MIDI 2 System On messages will be received (ON) or not (OFF).
Receive GS Reset OFF, ON Specifies whether GS Reset messages will be received (ON) or not (OFF).
Parameter Value Explanation
MMC
MMC (MIDI Machine Control) is a specification that allows MIDI messages to be used to control devices such as tape recorders, VTR’s, and
digital recording systems. Thirty-seven MMC commands are available, including Stop and Play.
MMC Mode
MASTER,
SLAVE When synchronizing the Fantom-Xa with a hard disk recorder, such as one from the Roland VS
series, specify which synchronization signal the Fantom-Xa’s sequencer will use for operation.
MASTER: The Fantom-Xa will be the master. Use this setting when you want other devices to
follow the operation of the Fantom-Xa.
SLAVE: The Fantom-Xa will be the slave. Use this setting when you want the Fantom-Xa to
receive MMC (MIDI Machine Control) from an external device and operate accordingly.
MMC Output OFF, ON Turn this “ON” if you want to synchronize with a hard disk recorder, such as one from the Ro-
land VS series.
When set “ON,” MMC (MIDI Machine Control) related commands (Play, Stop and Locate)
will be transmitted.
MTC
MTC Sync Output OFF, ON Set this parameter “ON” when you want MTC (MIDI Time Code) to be transmitted to an exter-
nal MIDI device. If not, set it “OFF.”
MTC Frame Rate 24, 25, 29N,
29D, 30 MTC frame rate
Make sure that the same mode is set in both master and slave devices.
24: 24 frames per second
25: 25 frames per second
29N: 29 frames per second, non-drop format
29D: 29 frames per second, drop format
30: 30 frames per second, non-drop format
* When synchronizing with a hard disk recorder such as the Roland VS series, any frame rate is all
right—as long as the setting matches that of the Fantom-Xa. However, when synchronizing operation
with video devices such as video decks, the video device’s frame rate is fixed, so the Fantom-Xa’s setting
must correspond to that frame rate.
MTC Offset Time Hour 0–23 (hours) Coordinates the playback timing of the Fantom-Xa and the external device in an hour units.
MTC Offset Time Minute 0–59 (minutes) Coordinates the playback timing of the Fantom-Xa and the external device in a minute units.
MTC Offset Time Second 0–59 (seconds) Coordinates the playback timing of the Fantom-Xa and the external device in a second units.
