Page 158: 158 adding effects
158
Adding Effects
In Patch mode you can use two multi-effects (MFX1, MFX2), one chorus, and one reverb. Multi-effect 1 (MFX1) will operate according to the effect
settings of the patch or rhythm set assigned to the Keyboard part. Multi-effect 2 (MFX2) will operate according to the effect settings of the patch or
rhythm set assigned to the Pad part. Chorus and reverb will both operate according to the settings of the patch or rhythm set assigned to either the
Keyboard part or the Pad part.
Here you can make overall settings for effects, and the output destination and level of each signal.
fig.Routing
For details on these settings, refer to
Applying Effects in Patch Mode
Specifying How the Sound Will Be Output (Routing)
Parameter
Value
Explanation
Part Select
KBD, PAD
Part for which you want to make settings
Tone Select
(Rhythm Key
Select)
1–4 (A0–C8)
Tone (or rhythm tone) for which you want to make settings
This parameter is Rhythm Key Select when a rhythm set is being selected. You can select the
rhythm tone (A0–C8) for which you want to make settings.
Tone Output
Level
0–127
Level of the signal sent to the output destination specified by Output Assign
Tone Chorus
Send Level
0–127
Level of the signal sent to chorus for each tone
Tone Reverb
Send Level
0–127
Level of the signal sent to reverb for each tone
MFX Type
0–78
Selects from among the 78 available multi-effects.
For details on multi-effects parameters, refer to
Patch Output
Assign
MFX, A, B,
1–4, TONE
Specifies how the direct sound of each patch will be output.
MFX:
Output in stereo through multi-effects. You can also apply chorus or reverb to the sound that
passes through multi-effects.
A, B:
Output to the OUTPUT A (MIX) jack or OUTPUT B jack in stereo without passing through
multi-effects.
1–4:
Output to the INDIVIDUAL 1–4 jacks in mono without passing through multi-effects.
TONE:
Outputs according to the settings for each tone.
This parameter is Rhythm Output Assign when a rhythm set is being selected. You can specifies for
each rhythm set how the direct sound will be output.
* If the Mix/Parallel parameter is set to “MIX,” all sounds are output from the OUTPUT A (MIX) jacks in
Tone Output
Assign
MFX, A, B,
1–4
Specifies how the direct sound of each tone will be output.
MFX:
Output in stereo through multi-effects. You can also apply chorus or reverb to the sound that
passes through multi-effects.
A, B:
Output to the OUTPUT A (MIX) jack or OUTPUT B jack in stereo without passing through
multi-effects.
1–4:
Output to the INDIVIDUAL 1–4 jacks in mono without passing through multi-effects.
* If the Patch Output Assign is set to anything other than “TONE,” these settings will be ignored.
• When the Structure Type parameter has a setting of Type “2”–”10,” the outputs of tones 1 and 2
will be combined with tone 2, and the outputs of tones 3 and 4 will be combined with tone 4. For
this reason, tone 1 will follow the settings of tone 2, and tone 3 will follow the settings of tone 4 (p.
38).
* If the Mix/Parallel parameter is set to “MIX,” all sounds are output from the OUTPUT A (MIX) jacks in
MFX Output
Level
0–127
Volume of the sound passed through the multi-effects
MFX Chorus
Send Level
0–127
Amount of chorus for the sound passed through multi-effects
