4. Configuration

3160-A2-GB24-10

March 2001

4-21

Configuring SNMP Traps

A trap is an unsolicited message that is sent from the DSU/CSU to an SNMP
manager when the DSU/CSU detects certain pre-specified conditions. These
traps enable the SNMP manager to monitor the state of the network.

The SNMP Trap configuration option must be enabled for trap messages to be
sent over the communications link. You must specify the number of SNMP
managers that are to receive traps from this DSU/CSU, an IP address for each
SNMP manager specified, and the type of traps to be sent from this DSU/CSU. For
more information, refer to

Appendix C, Configuration Options

, and

SNMP Traps

in

Chapter 7, Monitoring and Troubleshooting.

Enabling SNMP Trap Messages

Procedure

To enable SNMP trap messages from this DSU/CSU:

1. From the top-level menu screen, select Cnfig.

2. Select the configuration option set to be copied into the Edit area by using the

appropriate Function key. Use the scroll keys, if necessary.

3. Select Edit.

4. From the Edit screen, press the

key until the Alarm selection appears on

the screen.

5. Select Alarm.

6. Press F1 (Next) until the SNMP Trap configuration option appears.

7. Press F2 (Enab) to enable trap messages over the SNMP management link.

F1

F2

F3

Edit:
User Alarm Mgmt

F1

F2

F3

SNMP Trap:
Next Enab Disab
