D. Configuration Worksheets
D-6 March 2001 3160-A2-GB24-10
Prt3 Options Value (Default in Bold)
Port Type E530, V.35, RS449, X.21
Base Rate Nx64, Nx56
Net DCLB Disab, V.54, FT1, Both
Port LB Disab, DTLB, DCLB, Both
All Ones Disab, DTR, RTS, Both
Rcv Yellow None, Halt
Tx Clock Int, Ext
InvertTxC Auto, Enab, Disab
InvrtData Enab, Disab
EDL Enab, Disab
Err Rate 10E- 4, 10E-5, 10E-6, 10E-7, 10E-8, 10E-9
Near-end Disab, Maint, Send, Both
Far-end Disab, Maint
Mgmt Link Enab, Disab
Prt4 Options Value (Default in Bold)
Port Type E530, V.35, RS449, X.21
Base Rate Nx64, Nx56
Net DCLB Disab, V.54, FT1, Both
Port LB Disab, DTLB, DCLB, Both
All Ones Disab, DTR, RTS, Both
Rcv Yellow None, Halt
Tx Clock Int, Ext
InvertTxC Auto, Enab, Disab
InvrtData Enab, Disab
EDL Enab, Disab
Err Rate 10E- 4, 10E-5, 10E-6, 10E-7, 10E-8, 10E-9
Near-end Disab, Maint, Send, Both
Far-end Disab, Maint
Mgmt Link Enab, Disab
