2. Installation

2-4

March 2001

3160-A2-GB24-10

Figure 2-6.

Connection through the 10BaseT Port

Figure 2-7.

Remote Access through FDL/EDL

Important Instructions

Read and follow all warning notices and instructions marked on the DSU/CSU or
included in this guide.

For a complete listing of the safety instructions, see

Important Safety Instructions

at the beginning of this guide.

HANDLING PRECAUTIONS FOR
STATIC-SENSITIVE DEVICES

This product is designed to protect sensitive components from damage
due to electrostatic discharge (ESD) during normal operation. When
performing installation procedures, however, take proper static control
precautions to prevent damage to equipment. If you are not sure of the
proper static control precautions, contact your nearest sales or service
representative.

NETWORK

LAN

ROUTER

ETHERNET

99-15008-02

DSU/CSU

LAN

ROUTER

ETHERNET

FDL/EDL

99-15010-02

NETWORK

DSU/CSU

DSU/CSU

!

496-15104
